REPAIR GUARD- EPOX MORTAR
Satisfied compressive Strength according IS 4031 (part-6) 1988
- View in video
Product Rating
Epoxy based Repair mortar
REPAIR GUARD -EPOX MORTAR
REPAIR GUARD -EPOX MORTAR Is a non-shrink and high mechanical strength properties epoxy-based mortar. It is a three-component system comprising of Base ( Resin), Hardener and Quartz filler.
Additional Information:
| Property | Value |
|---|---|
| Base | Epoxy Resin (Two Component) |
| Appearance | Brown Liquid |
| Mix Proportion (By Weight) | EPOX – A – LV : EPOX – B – LV, 2:1 |
| Quartz Filler | 15-16 PBW |
| Shelf Life | 1 year in tightly sealed container |
| Pot Life | 50 mins for 1 kg mix at 25° C |
| Curing | 24 hours in air |
Test Parameters
| Test Parameter | Test Method | Test Result | Measurement Unit |
|---|---|---|---|
| Viscosity at 25° C | ASTM D 2196 | 550 - 600 CPS | CPS |
| Compressive Strength (7 days) | ASTM C 881 / ASTM D 695 | 60 N/mm² | N/mm² |
| Tensile Adhesion Strength | ASTM C 881 / ASTM D 695 | 20 N/mm² | N/mm² |
Packaging
| Part | Weight |
|---|---|
| Part A | 20 kg |
| Part B | 10 kg |
- High Mechanical Strength: Provides compressive strength of 60 N/mm² for durable repairs.
- Non-Shrink Formula: Ensures long-term stability without shrinkage.
- Excellent Adhesion: Bonds firmly to concrete and masonry structures.
- Low-Temperature Usability: Suitable for varied environmental conditions.
- Fast Curing Time: Cures in 24 hours for quick and effective repairs.
- REPAIR GUARD -EPOX MORTAR is gives strength and durability of structural elements.
- Used as a mortar for deteriorated concrete structures like beams and columnsfor strength and durability.
- Corrosion damaged structures.
- Dilapidated RCC structures.
Why Choose REPAIR GUARD - EPOX MORTAR?
- Reliable epoxy mortar for structural reinforcement and concrete restoration.
- Long-lasting durability and superior bonding, ensuring high-performance repairs.
Want to know more? Connect on 9323244244 or Request a Free Consultation!
Frequently Asked Questions (FAQs)
What is REPAIR GUARD - EPOX MORTAR used for?
REPAIR GUARD – EPOX MORTAR is a high-strength, non-shrink epoxy mortar designed for repairing deteriorated concrete structures, beams, and columns. It enhances structural durability and bonding strength.
How does REPAIR GUARD - EPOX MORTAR improve concrete strength?
It provides high mechanical and adhesive strength, ensuring a strong bond between structural elements while being resistant to shrinkage and environmental damage.
Can REPAIR GUARD - EPOX MORTAR be used in low temperatures?
Yes, this epoxy-based repair mortar is suitable for low-temperature applications, maintaining its bonding and curing properties even in challenging conditions.
What are the key technical specifications of REPAIR GUARD - EPOX MORTAR?
It features a compressive strength of 60 N/mm² and tensile adhesion strength of 20 N/mm², making it highly effective for concrete restoration and reinforcement.
How should REPAIR GUARD - EPOX MORTAR be stored?
Store in sealed containers away from direct sunlight. It has a shelf life of 12 months when properly stored.
