High-Performance Epoxy Coal Tar Coating
STRUCT GUARD –COAL TAR is two packs, high build epoxy coal tar coating system for protection of steel structure in marine, sub-soil and saline environment. Coal tar epoxy coating is a popular choice for protecting surfaces in demanding environments, such as marine, industrial, and infrastructure applications.
Additional Information:
| Property | Value |
|---|---|
| Part A : Part B | 4 : 1 |
| Induction Time | 30 minutes |
| Pot Life at 30°C | 4 Hours |
Product Information
| Property | Value |
|---|---|
| Type | Two Pack |
| Composition | Epoxy resin, suitably pigmented with coal tar |
| Color | Black |
| Gloss | Semi Glossy |
| Drying Time at 30°C | Surface Dry: 2 hours, Hard Dry: 24 hours, Full Cure: 5 days |
| Overcoating Interval at 30°C | Min: 24 hours, Max: 1 month (if surface is cleaned from contamination) |
| Volume Solids | Approx. 80±3% |
| Recommended DFT (Coat) | 200 - 400 microns |
| Theoretical Covering Capacity | 2 - 4 sq.mtr per liter |
| Flash Point | Part A: 27°C, Part B: 27°C |
| Shelf Life (Cool & Dry Place) | At least 12 months |
| Hardener | Struct Guard-Coal Tar B |
- High Anti-Corrosion Protection: Shields steel structures from marine and industrial damage.
- Superior Water Resistance: With stands freshwater and seawater exposure.
- Long-Lasting Durability: Ensures extended service life in harsh conditions.
- Easy Application & High Coverage: Provides 2-4 sq.m per liter for efficient usage.
- Fast Drying & Strong Adhesion: Surface dry in 2 hours, hard dry in 24 hours.
- Thick Protective Coating: Recommended DFT of 200-400 microns per coat.
- Marine environments: ship hulls, offshore platforms, and dock structures.
- Industrial facilities: chemical plants, refineries, and power generation units
- Water and wastewater treatment plants: tanks, pipes, and valves
- Bridges and highways: steel structures and concrete surfaces
- Oil and gas industry: pipelines, tanks, and equipment
- Concrete protection: basements, foundations, and concrete structures
- Steel protection: tanks, pipes, and equipment
- Roofing and flooring: industrial and commercial buildings.
Why Choose STRUCT GUARD – COAL TAR?
- Reliable, high-performance epoxy coal tar coating for maximum protection in harsh environments.
- Ensures long-term durability and corrosion resistance, making it ideal for marine and industrial applications.
Want to know more? Connect on 9323244244 or Request a Free Consultation!
Frequently Asked Questions (FAQs)
What is STRUCT GUARD – COAL TAR used for?
STRUCT GUARD – COAL TAR is a high-build epoxy coal tar coating designed for protecting steel structures in marine, sub-soil, and saline environments. It provides outstanding anti-corrosion performance.
How does STRUCT GUARD – COAL TAR protect steel structures?
It forms a protective barrier against fresh and seawater, preventing corrosion in coastal, industrial, and polluted environments while offering long-term durability.
Can STRUCT GUARD – COAL TAR be applied over existing coatings?
Yes, it can be applied over existing epoxy coatings after surface preparation, including high-pressure water washing and roughening for proper adhesion.
What are the drying and curing times for STRUCT GUARD – COAL TAR?
It has a surface dry time of 2 hours, hard dry time of 24 hours, and full curing in 5 days, ensuring quick and effective protection.
How should STRUCT GUARD – COAL TAR be stored?
Store in a cool, dry place away from direct sunlight. It has a shelf life of 12 months in its original sealed packaging.
